Strainers

Metraflex Strainers Meet These Industry Specs:

FCI 73-1, Pressure Rating Standard for “Y” Type Strainers

FCI 78-1, Pressure Rating Standard for Pipeline Strainers Other than “Y” Type

Product Categories

Group 21 Created with Sketch.

Style LPD Y Strainer

  • 30% larger screen size
  • Hundreds of dollars in energy-savings yearly
  • Streamlined design means straight, smooth flow
  • Maximizes NPSH
  • 2 thru 16 inch, 125#
  • More efficient pump performance
3D Drawings
Group 3 Copy 3 Created with Sketch.
Submittals
Close

LPD Y-Strainer Submittal 2"-8"

LPD Y-Strainer Submittal 10"-24"

Style LPD-Mag Y Strainer

  • Protect pump systems from iron oxide build-up
  • Remove oxides with blow-down, while in use
  • Easily adapted to existing LPD Y Strainer
  • 2-1/2 thru 12 inch, 125#
  • More efficient pump performance
Group 3 Copy 3 Created with Sketch.
Submittals
Close

LPD-Mag 2-8"

LPD-Mag 10"+

BasketMag

  • Protect pump systems from iron oxide build-up
  • Available for basket strainers in 3-12” Sizes
  • Fin design creates vortices to enhance magnet capabilities
  • Easily removable magnet allows for quick cleaning
Group 3 Copy 3 Created with Sketch.
Submittals
Close

Basket Mag Submittal

Style TF 125# Y Strainer

  • Steam: Max 125 psi at 350ºF
  • Water/oil/gas: Max 175 psi at 150ºF
3D Drawings
Group 3 Copy 3 Created with Sketch.
Submittals
Close

TF 125# Y Strainer Submittal

Style TF2 250# Y Strainer

  • Steam: Max 250 psi at 400ºF
  • Water/oil/gas: Max 400 psi at 150ºF
  • Pre-drilled ports
3D Drawings
Group 3 Copy 3 Created with Sketch.
Submittals
Close

TF2 250# Y Strainer Submittal

Style B-1-T Basket Strainer

  • Sizes 2-inch thru 12-inch
  • Removes debris than can damage equipment
  • Helps maximize pump life
  • Steam: up to 125 psi/350ºF
  • Water/oil/gas: Up to 175 psi/150ºF
  • ISO 9002
3D Drawings
Group 3 Copy 3 Created with Sketch.
Submittals
Close

B-1-T Basket Strainer Submittal

Style TS 250# Y Strainer

  • Steam: Max 250 psi at 400ºF
  • Water/oil/gas: Max 400 psi at 150ºF
3D Drawings
Group 3 Copy 3 Created with Sketch.
Submittals
Close

Y-Type Strainer Submittal - TS Model

Style B-1-T-C Basket Strainer

  • Clamp cover
  • Sizes 2-inch thru 12-inch
  • Removes debris than can damage equipment
  • Helps maximize pump life
  • Water: Up to 200 psi/200ºF
  • ISO 9002
3D Drawings
Group 3 Copy 3 Created with Sketch.
Submittals
Close

B-1-T-C Basket Type Strainer Submittal

Style SSFS Y Strainer

  • 1/2-inch thru 2-inch
  • Stainless steel body and screen
  • Water, oil, gas (non-shock)
  • Max pressure: 200 psi
  • Max temperature: 150ºF
Group 3 Copy 3 Created with Sketch.
Submittals
Close

SSFS Y Strainer Submittal

Style SSFT Y Strainer

  • 1/2-inch thru 2-inch
  • Stainless steel body and screen
  • Water, oil, gas (non-shock)
  • Max pressure: 200 psi
  • Max temperature: 150ºF
Group 3 Copy 3 Created with Sketch.
Submittals
Close

SSFT Style Y-Strainer Submittal

Style S 250# Y Strainer

  • Steam: Max 250 psi at 400ºF
  • Water/oil/gas: Max 400 psi at 150ºF
3D Drawings
Group 3 Copy 3 Created with Sketch.
Submittals
Close

S 250# Y Strainer Submittal

Style M1KN 125# Y Strainer

  • Steam: 100-125 psi at 350º-450ºF
  • Water/oil/gas: 150-200 psi at 150ºF
3D Drawings
Group 3 Copy 3 Created with Sketch.
Submittals
Close

M1KN 125# Y Strainer Submittal

Style M2KN 250# Y Strainer

  • Steam: Max 250 psi at 400ºF
  • Water/oil/gas: Max 400 psi at 150ºF
3D Drawings
Group 3 Copy 3 Created with Sketch.
Submittals
Close

M2KN 250# Y Strainer Submittal
